Data logger – Data preprocessing and -recording
For data preprocessing and –recording there are several datalogger included in the THIES delivery program. They acquire and save the measuring values of the connected sensors. Extended functions, such as broken-wire detection, are adapted especially to THIES products. Thus, each sensor can be tested for correct function during measuring value acquisition. An integrated display for parametrization and for displaying the instantaneous values complete the function.
For transmitting the data to superordinate systems there are wired solutions, such as RS485 or Ethernet, available as well as wireless transmission such as GPRS.
Product
Product name
Product name / Brief description
Datalogger DLU
9.1711.10.0x0Datalogger DLU
9.1711.10.0x0
*The datalogger records measuring values via two serial interfaces RS485/422, and via integrated analogue and digital input channels. The serial interfaces are designed for the connection of sensors with MODBUS-RTU interface, and for sensors with THIES data protocol. It is possible to connect up to 32 devices to one bus. The analogue inputs serve for connecting a humidity temperature sensor with PT100, and voltage output, and up to three sensors with voltage output 0 … 10 V. The digital inputs support the direct connection of a wind direction transmitter with synchronous-serial output, and two precipitation meters with pulse output.
9.1711.10.0x0
*The datalogger records measuring values via two serial interfaces RS485/422, and via integrated analogue and digital input channels. The serial interfaces are designed for the connection of sensors with MODBUS-RTU interface, and for sensors with THIES data protocol. It is possible to connect up to 32 devices to one bus. The analogue inputs serve for connecting a humidity temperature sensor with PT100, and voltage output, and up to three sensors with voltage output 0 … 10 V. The digital inputs support the direct connection of a wind direction transmitter with synchronous-serial output, and two precipitation meters with pulse output.
Data logger DL16
9.172x.xx.xxxData logger DL16
9.172x.xx.xxx
*The DL16 meets all requirements for meteorological applications. Its flexibility allows the measuring value acquisition of common sensors as well as the connection of instruments from other manufacturers via RS485, RS422, Ethernet, and also via the analogue inputs.
9.172x.xx.xxx
*The DL16 meets all requirements for meteorological applications. Its flexibility allows the measuring value acquisition of common sensors as well as the connection of instruments from other manufacturers via RS485, RS422, Ethernet, and also via the analogue inputs.
Data logger DLX Met
9.1756.x0.xxxData logger DLX Met
9.1756.x0.xxx
*The datalogger DLx-MET is a complete measuring system for the automatic data acquisition
and storing of meteorological data (for ex. wind velocity, wind direction, temperature,
precipitation, rel. air humidity, radiation etc.).
9.1756.x0.xxx
*The datalogger DLx-MET is a complete measuring system for the automatic data acquisition
and storing of meteorological data (for ex. wind velocity, wind direction, temperature,
precipitation, rel. air humidity, radiation etc.).
Datalogger DLN
5.1756.00.000Datalogger DLN
5.1756.00.000
*The datalogger acquires the output pulse measurement values (0,1 mm prec/imp.) of max. 2 precipitation transmitters as well as one temperature value from a PT100.
5.1756.00.000
*The datalogger acquires the output pulse measurement values (0,1 mm prec/imp.) of max. 2 precipitation transmitters as well as one temperature value from a PT100.
SD-Card
9.2200.00.000SD-Card
9.2200.00.000
*Serves as portable data carrier for reading the measuring data out from data logger
9.2200.00.000
*Serves as portable data carrier for reading the measuring data out from data logger
Matching accessories will be displayed in the detail view
